Why Quad-Lock Insulating Concrete Forms?
Advantages of Building with Quad-Lock Insulated Concrete Forms
Owners of Quad-Lock ICF buildings consistently praise their energy efficiency, living comfort, noise reduction, and strength.
After building and living in an ICF house, I can say with 100 percent confidence that it was the right choice for our dream home. After 30 years in home construction, I will never go back to conventional built - ever!"
Barry Oberpriller, owner-builder of Casa del Sol
We felt that a panel system, as opposed to a block, gave us the best chance of dealing with the structural steel issues that arose. We were correct. The structure included hundreds of zone reinforced columns (within the wall form) that stabilize the building during seismic events. The Quad-Lock system allowed us to thread the ties through these zones as opposed to building the zones within the block form, saving us countless man hours.”
Chris Doyle of Willow Lane Construction
View Quad-Lock's Concrete Home Benefits video or download the "Quad-Lock All About ICFs PDF" (9.8mb)
Quad-Lock offers the widest range of R-Values in the industry
Ultra Energy-Efficient
With Quad-Lock you can build walls with your choice of insulation value, from R-22 to R-59 - the highest ICF R-Values in North America. Choose the optimum R-Value depending on your local climate and energy-saving goals. High insulation values combine with low air infiltration and the thermal mass of the concrete to keep occupants comfortable, healthy, and productive, while saving significantly on energy costs.
Fast, Simple, Accurate
The Quad-Lock Insulated Concrete Form System is infinitely versatile, allowing design and construction flexibility unmatched in other types of concrete forming! Pre-Set Ledger Board with Bolts
Engineered
Quad-Lock is an engineered system - designed by builders for builders. Approved by the International Code Council and many other code agencies, and tested by Intertek Testing Services,
Keep your loved ones and belongs safe from natural disasters with a Quad-Lock ICF & Concrete Safe Room
Safe, Fire Rated
Quad-Lock Panels are manufactured from high density, biologically safe, fire retardant expanded polystyrene (EPS). The Quad-Lock Building System will not support combustion. The fire resistance of a finished Quad-Lock wall with 8" concrete thickness is 4 hours per UL tests.
Solid
Quad-Lock ICF construction gives you a sold, reinforced concrete wall - your choice of 4" to 14" thick using six standard length ties (4, 6, 8, 10, 12, & 14 inches), and greater widths by using the 12" Extender Tie in combination with the standard ties and additional Extender Ties. No foam tunnels through the concrete. No thin/thick sections. No worries about rotting. No insects crawling through your walls. Just solid, uniform, insulated concrete walls with standard rebar.
World Class Support
Green Harbor Building Systems, LLC is equipped to answer your questions, prepare detailed estimates, and assist at the jobsite. We are also ready to assist with quantity pricing, job site training, product seminars and training. Our Installation Video, Product Manual, and other informative technical and promotional literature tells you exactly how to build with Quad-Lock.
For a more detailed and pictorial depiction of Quad-Lock ICFs, view our "All About Quad-Lock ICFs" Guide
